Outboard motor 2 Stroke

T30S hp 2 stroke

Overall length	mm(in.)	720(28.4)
Overall width	mm(in.)	470(18.5)
Overall heigth	mm(in.)	1230(48.4)
Transom heigh	mm(in.)	423(16.7)
Weight	kg	52
Full throttle operating range	r/min	4500-5500
Maximum output:kw(HP)@r/min		22(30)@5000
Idling speed (in neutral)	r/min	1000-1100
Engine type		2-stroke
Cylinders		2
Displacement	cm³	498
Bore x stroke	mm(in.)	67x60(2.64x6)
Ignition system		CDI
Control system		Tiller
Starting system		Manual
Gear positions		Forward-neutral-reverse
Gear ratio		1.85(24/13)
Trim and tilt system		Nanual tilt
Integral fuel tank capicity	L	/
Separate fuel tank capicity	L	24
Maximum fuel waste	L/h	11
Engine oilcapacity/withoutoilfilter	L	Fuel:oil ratio:50:1
Gear oil capacity	ML	320
Propeller options*	in	3-9 7/8"×12"
