Outboard motor 2 Stroke

3.5hp outboard motor boat engine


Overall length	mm(in.)	620(24.4)
Overall width	mm(in.)	220(8.6)
Overall heigth	mm(in.)	960(37.8)
Transom heigh	mm(in.)	432(17.0)
Weight	kg	10
Full throttle operating range	r/min	4200-5300
Maximum output:kw(HP)@r/min		2.5(3.5)@5000
Idling speed (in neutral)	r/min	1250-1350
Engine type		2-stroke
Cylinders		1
Displacement	cm³	64.6
Bore x stroke	mm(in.)	47x43(1.85x1.69)
Ignition system		CDI
Control system		Tiller
Starting system		Manual
Gear positions		Forward-neutral
Gear ratio		2.08(27/13)
Trim and tilt system		Nanual tilt
Integral fuel tank capicity	L	1.2
Separate fuel tank capicity	L	\
Maximum fuel waste	L/h	0.9
Engine oilcapacity/withoutoilfilter	L	Fuel:oil ratio:50:1
Gear oil capacity	ML	45
Propeller options*	in	3x7 1/4"x6"
